The new modular railway platform has been developed to meet the requirements of modern railway systems.
Designed for onboard applications and critical infrastructure projects, it combines control, communication, data acquisition and Safety functions within a single scalable and future-proof architecture.
Its modular approach makes it suitable for rolling stock projects, signalling systems and advanced railway communication architectures.
The new modular railway platform can be used for:
The platform has been designed to consolidate multiple functions within a single architecture, simplifying integration while reducing lifecycle costs.
| Feature | Specification |
|---|---|
| Compliance | EN50155 |
| Architecture | Modular |
| Scalability | 1 to 16 modules |
| Operating Temp. | -40°C to +70°C |
| Power Supply | 24-110Vdc |
| Installation | Wall or Rack Mount |
| Height | 3U |
| Depth | 100 mm |
| Feature | Specification |
|---|---|
| Processor | STM32MP1C135 |
| Operating System | Linux |
| RAM | 512 MB DDR3L |
| Flash | 4 GB eMMC |
| Ethernet | 2 Independent Channels |
| Protocols | CAN-FD, RS-485, MVB |
| Programming | C / IEC 61131-3 STRATON |
| Feature | Specification |
|---|---|
| Processor | Hercules Dual Core Lockstep |
| RAM | 64 MB |
| Flash | 4 MB + 64 MB |
| Communication | CAN, Serial |
| Configuration | Dataplug |
| Programming | C / IEC61131-3 Functional Blocks |
| I/O Type | BI Reference | SIL2 Reference |
|---|---|---|
| Digital Inputs | DI16 | DI16S |
| Digital Outputs | DO8 | DO8S |
| Analog Inputs / Outputs | A8I4O | – |
| Analog Inputs | – | AI8S |
| High-Speed Inputs | HSI | HSIS |
The new modular railway platform simplifies the integration of equipment within modern railway architectures through native support of key communication protocols:
This connectivity enables seamless interoperability with onboard systems, field equipment and supervision centres.
Configure the platform to match the exact needs of your project.
Deploy from 1 to 16 modules within the same architecture.
Combine control, communication and Safety functions into a single platform.
Engineered to meet railway industry requirements and support long-term modernization programs.
